In the path selection just type / as will indicate the whole site.įor the public name, type in the external site name (in my case ) to work. Point out the internal site name to be the external site name () and browse for the CAS server. Next thing it to select the newly created web listener, for authentication delegation settings select Basic Authentication and finally All Authenticated Users.Ī nice one to complete the publishing of the OWA is to create a 'Publish Web Sites' rule and set it to deny, publish it as a single server and require SSL. In the public name, give it your external site name (). In the setting regarding internal site name, give it the external site name () and select the option below and browse for the CAS server. Select the option 'publishes single server' and require SSL. Next step is to create the publishing rule it will be done under the Tasks tab called 'Publish Exchange Web Client Access'.Ī wizard will start, setup a friendly name like OWA (Basic) and select the appropriate Exchange version, in my case it's Exchange 2010. When the creating is completed it should look like below. (Or else you will need to logon two times for using the OWA.) domain.local if you want to use the function.
#Forefront tmg 2010 windows#
The authentication setting that will be used is called HTML Form Authentication, make sure that Windows (Active Directory) is selected. Next screen select 'Assign a certificate for each IP address and point out the imported certificate. In my case I listen on External and Internal, also select a specific IP address on the External and Internal interface. Give it a friendly name, I called it "SSL Listener", set it up to require SSL, select the sources where it should listen to traffic from. Next step is to create the Web listener, it will be done in TMG Console under Firewall Policy, choose Toolbox and right click Web Listeners to create a new web listener. When it's done it should look like below. Go to Personal and right click, choose import and point at the file. The certificate import is easy, start a mmc console and add certificates for the local computer.
Best practice is to buy the certificate from a 3 rd part that is trusted root in most devices (,, , etc). Just to get the name resolution working fine with the rule and certificate.įirst thing to do is to import the certificate that is generated from the CAS server in my case it's a CA server on the DC that generated this certificate. On the TMG server in the hosts file I have edited it with notepad and pointed out the CAS server My TMG server is installed with Windows 2008 R2 圆4 with 2 Nics (E1000), running with an internal Nic setupĭefault Gateway: Pointing to my external gateway
#Forefront tmg 2010 update#
Stop Buy Orders and buying on Confirmation.A quick update… mostly news and a learning resource.You should give the rule a meaningful name like TMG RDP Management and then setup the rule to allow RDP (Terminal Services) traffic from the Internal network to the Local Host.Īt this point save all the new configuration and enjoy being able to manage your TMG box via RDP from your LAN. Next back in the left hand pane right click Firewall Policy and create a new access rule: In the far right pane, click on Toolbox and drill down into Computer Sets to find Enterprise Remote Management.ĭouble click Enterprise Remote Management to open the set and then use the Add button to ensure that your internal subnet is listed. Here’s how:įirst open up Forefront TMG Management console and in the left hand pane click on Firewall Policy. Until recently I was managing TMG via the console viewer on HyperV, however on Friday last week a colleague helped me setup internal RDP access for remote desktop. One of the other things is the Forefront TMG box that publishes various content to the Internet. The system runs on my new Dell Vostro 430 machine with i780 CPU and 16GB of RAM and hosts Exchange 2010 SP1 and Lync 2010 RC amongst other things. Over the last few weeks I have been building up a new home lab system for production and semi production testing.
